The ultra-deep hole/small hole electric discharge machine penetrates a hole of φ1.0 to a depth of 1500mm.

Electric discharge machining unit that has developed a new frontier to achieve an L/D of 1500.
It can machine small-diameter deep holes, which gun drills are not good at.

Drill head

name 6Z1800

Body dimensions (width × depth × height) 435×373×2558mm

Machine body weight 170kg

Stroke 1841mm

Maximum electrode length 1800mm

Diameter of the electrodes φ0.3～3.0mm

name	6Z1800
Body dimensions (width × depth × height)	435×373×2558mm
Machine body weight	170kg
Stroke	1841mm
Maximum electrode length	1800mm
Diameter of the electrodes	φ0.3～3.0mm

name 6Z1800 Body dimensions (width × depth × height) 435×373×2558mm Machine body weight 170kg Stroke 1841mm Maximum electrode length 1800mm Diameter of the electrodes φ0.3～3.0mm

name 6Z1800

Body dimensions (width × depth × height) 435×373×2558mm

Machine body weight 170kg

Stroke 1841mm

Maximum electrode length 1800mm

Diameter of the electrodes φ0.3～3.0mm
